Punch Marine 1,000 Watt Class-bd 5-Channel Amplifier PM1000X5

Punch Marine 1,000 Watt Class-bd 5-Channel Amplifier PM1000X5

The PM1000X5 is a 500 Watt 5-channel amplifier with high dynamic power using Class-a/b technology on the front/rear channels, Class-bd for the subwoofer channel, and a conformal coated pc board designed for motorsport and marine applications.

Read More
0 Reviews
$749.99
+
Overview

The PM1000X5 1,000 Watt full-range 5-channel is the one-and-only amplifier you will need to run your entire system. Run dash speakers off the front channels, run back speakers off the rear channels and run subwoofer(s) off the 5th channel! Known world-wide for brute power, this amplifier offers a higher level of efficiency along with a tri-stage protection that covers thermal, over-current and short circuits.

  • High level input capable with Auto Turn-On circuit
  • Features C.L.E.A.N. Set-up
  • Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
  • 12dB/octave Butterworth crossover
  • On-board Punch EQ with +18dB boost @ 45Hz
  • Muted turn on
  • Stealth top mounted control panel
  • Cast aluminum heatsink
  • Short circuit protection
  • Over current protection
  • Infrasonic filter
  • 2/4 channel input switch
  • Marine grade two part epoxy coating on circuit boards
  • Marine grade stainless steel hardware
  • 2 Year Warranty
Technologies
CE Compliant
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

CEA-2006 Compliant
CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's ...

Class BD
Class BD

Class BD amplifiers have 75-80% efficiency ratings vs. 20-60% efficiency ratings of traditional class A/B amplifiers.

TRANS&#149;<em>ana</em>
TRANS•ana

Trans•ana is a Class A/B topology that simplifies the signal path of the amplifier allowing the ...

Balanced Differential Inputs
Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

Element Ready&#8482; - Amps
Element Ready™ - Amps

These amplifiers are protected against Dust, UV, Corrosion, and feature Stainless hardware.

DTM
DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

DSM
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and ...

MEHSA<sup>3</sup>
MEHSA3

MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

NOMAD
NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and ...

C.L.E.A.N. Set-Up
C.L.E.A.N. Set-Up

Patented circuit with in/out clip LEDs to help match a source to amp and optimize output.

Rockford Fosgate Avatar
Rockford Fosgate Avatar

These Avatars are a personal signature from the Rockford Fosgate team member who designed and engineered ...

Specifications
Input Sensitivity
150 mV - 12 V
Operating Voltage
9 - 16 VDC
Number of Channels
5
CEA-2006 Compliant
CEA-2006 Power Rating
75Wx4 + 150Wx1 @ 4Ω
≤1.0% THD+N
Tone Controls
Sub:
0dB to +18dB @ 45Hz
Signal Input
Input Switch: Hi/Low level input
Input Switch: 2/4 channel input
Hi/Low Level: 3 RCA Pair
Sub: front/sub input switch
Signal Output
-
Power Input Connector
Block
Power Wire Gauge
4 AWG
Speaker Output Connector
Block
Speaker Wire Gauge
12 AWG
Visual Indicators
Power/Protect/Thermal LED
Input Clip LED3
Output Clip LED1,2,3

LED Color Legend:
1BLUE: <0.5% THD
2VIOLET: 1% THD
3RED: 10%+ THD
Dimensions (H x W x D)
2.38 x 7.76 x 15.03 (in)
6.05 x 19.71 x 38.18 (cm)
Total Harmonic Distortion (THD+Noise)
<1.0%
Average Current Draw (13.8V Music)
75 A
Max. Current Draw (13.8V Sinewave)
150 A
Recommended Fuse
(not included)
150 A
Suggested Alternator
100 A
Rated Power
(RMS Continuous Power)
75 Watts x 4 +
150 Watts x 1 @ 4-Ohm

125 Watts x 4 +
300 Watts x 1 @ 2-Ohm

N/A +
500 Watts @ 1-Ohm
Total Power
(Sum of Rated Power)
1000 Watts
Bridgeable
Yes (front/rear channels)
Crossover Controls
Front: 50Hz - 250Hz High-Pass @ 12dB/Octave
Rear: 50Hz - 250Hz High-Pass @ 12dB/Octave
Sub: 50Hz - 250Hz Low-Pass
Sub: 28Hz infrasonic filter @ 12dB/Octave
Heat Sink Type
Cast
Cooling
Convection
Remote Controls
Optional Punch Level Control (PLC2) Ready
Circuit Topology Class
Class A/B + Class BD (Sub)
Frequency Response
Front/Rear: 20Hz - 20kHz +/-3dB
Sub: 20Hz - 500Hz +/-3dB
Shipping Weight
15.3 Lbs. (6.93 Kg.)
Dynamic Power
(PVC/PowerCube®)
115 Watts x 4 +
299 Watts x 1 @ 4-Ohms 0° Res

190 Watts x 4 +
540 Watts x 1 @ 2-Ohms 0° Res

N/A +
863 Watts x 1 @ 1-Ohm 0° Res
Efficiency (average)
Front/Rear: 66% @ 4-Ohm
Sub Channel: 80% @ 4-Ohm
Dimensional Diagram
Support

Knowledge Base Articles

  • No Knowledge Base articles

Show all Knowledge Base topics

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


View Process

Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.





























Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
