Punch Marine 10" SVC 4-Ohm Subwoofer PM210S4

Front View of Subwoofer with White Trim Ring and Stainless Steel Grille
Front View of Subwoofer without Trim Ring and Grille
Back 3/4 View of Subwoofer
Profile View of Subwoofer with White Trim Ring and Stainless Steel Grille
Side View of Subwoofer without Trim Ring and Grille
Profile View of Subwoofer with White Trim Ring and Stainless Steel Grille
3/4 View of Subwoofer without Trim Ring and Grille
Profile View of Subwoofer without Trim Ring and Grille

Punch Marine 10" SVC 4-Ohm Subwoofer PM210S4

The PM210S4 is a white 10" subwoofer designed for marine watercraft or powersports applications. It features a stainless steel sport grille and is UV and moisture resistant. Can be used in sealed, vented or infinite baffle installations.

• This model replaced by the M2D2-10S

Read More
0 Reviews
Discontinued
Overview

The PM210S4 is a white 10” subwoofer designed with weatherproofing technology specific for use in marine watercraft or powersports applications. It features a stainless steel sport grille and is UV and moisture resistant. This woofer is so versatile, it can be used in sealed, vented or infinite baffle installations.

FEATURES AT A GLANCE

  • 100% UV stable Centrex® injection molded plastic parts
  • UV and Salt-Fog resistant TPE (Thermo-Plastic Elastomer) surround
  • Injection molded mineral filled polypropylene cone body with UV inhibitors
  • True Marine Grade compliance
  • 18 gauge corrosion resistant removable Stainless Steel grille cover insert
  • Internal magnetic shielding
  • Ultra-flexible fully insulated silicone lead wire
  • Removable trim ring/grille
  • Linear, high excursion matched motor magnetics and suspension design
  • Moisture, tear and fatigue resistant Aramid fiber spider
  • Available in black or white
  • Proprietary corrosion resistant spring loaded push terminals
  • 2-Year Warranty
Technologies
ASTM Test Standards

Marine Grade standards ensure resistance to extreme environments.

Learn more
VAST Surround - Marine

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating cone area up to 25%.

Learn more
FlexFit Basket - Marine Sub

The slot mounted frame pattern allows fine-tuning of the subwoofer's mounting position.

Learn more
Element Ready™ | Subwoofers

All components are protected against harsh outdoor elements like Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
Anodized Aluminum Voice Coil Former

Rockford Fosgate subwoofers use anodized aluminum voice coil formers for superior heat dissipation (up to 100° ...

Learn more
Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.

Learn more
CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.

Learn more
Specifications
Nominal Impedance
4-Ohm
Mounting Depth
5.5 in. (140 mm)
Shipping Weight
11.75 Lbs. (5.3 Kg.)
Voice Coil Diameter
2" aluminum
CEA-2031 Compliant
CEA-2031 Guidelines
Cutout Diameter
9.0 in. (228 mm)
Woofer Displacement
0.154 cu. ft. (4.35 Liters)
Qes
0.64
Vas (Liters)
20.2
SPL (dB @ 1w/1m)
86
Fs (Hz)
45
Qts
0.57
Qms
9.00
Magnet Weight (oz)
54.4 oz. (1.54 Kg)
Xmax (mm)
10
Size
10"
Power Handling (Watts RMS)
250 Watts RMS
500 Watts Max
Speaker Connector
Dual 8 AWG compression
Le (mH)
0.3
Sd (cm2)
346
Re (Ohms)
3.6
Compatibility
Support

Knowledge Base Articles

  • No Knowledge Base articles

Show all Knowledge Base topics

Ask Our Experts

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
