Punch Marine 600 Watt 4-Channel Amplifier PM600X4

Punch Marine 600 Watt 4-Channel Amplifier PM600X4

The PM600X4 is a 600 Watt 4-channel amplifier with high dynamic power using Class-a/b technology and a conformal coated pc board designed for motorsport and marine applications.

Read More
0 Reviews
$499.99
+
Overview

The Punch PM600X4 multi-channel amplifier is versatile to power any audio system configuration. In addition to 4-channel stereo mode, you can bridge both channels to create a high power 2-channel amp, or run stereo speakers on the front with subwoofers on the rear in 3-channel mode. The variable HP/LP crossover and built-in Punch EQ allows for precise tuning of Bass frequencies and the Pass-Thru RCA jacks provide flexibility as your system grows and keeping Y-adapters to a minimum.

  • High level input capable with Auto Turn-On circuit
  • RCA pass-thru outputs
  • Features C.L.E.A.N. Set-up
  • Optional remote Punch Level Control (PLC2) ready (w/ input clip indicator)
  • 12dB/octave Butterworth crossover
  • On-board Punch EQ with +18dB boost @ 45Hz
  • Muted turn on
  • Stealth top mounted control panel
  • Cast aluminum heatsink
  • Short circuit protection
  • Over current protection
  • Marine grade two part epoxy coating on circuit boards
  • Marine grade stainless steel hardware
  • 2 Year Warranty
Technologies
CEA-2006 Compliant
CEA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's ...

CE Compliant
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

TRANS&#149;<em>ana</em>
TRANS•ana

Trans•ana is a Class A/B topology that simplifies the signal path of the amplifier allowing the ...

Balanced Differential Inputs
Balanced Differential Inputs

Differential inputs eliminate noise picked up by signal cables.

Element Ready&#8482; - Amps
Element Ready™ - Amps

These amplifiers are protected against Dust, UV, Corrosion, and feature Stainless hardware.

DTM
DTM

Dynamic Thermal Management evenly distributes excess heat across entire amplifier heatsink.

DSM
DSM

DSM utilize 1% tight-tolerances improving efficiency of the circuit, decreases cross-talk from other discrete components and ...

MEHSA<sup>3</sup>
MEHSA3

MEHSA3 reduces MOSFET temperatures, lowers distortion, increases durability and prolongs the output device life span.

NOMAD
NOMAD

NOMAD is a "real time" analog computer that protects your amplifier from shorting speaker wires and ...

Rockford Fosgate Avatar
Rockford Fosgate Avatar

These Avatars are a personal signature from the Rockford Fosgate team member who designed and engineered ...

C.L.E.A.N. Set-Up
C.L.E.A.N. Set-Up

Patented circuit with in/out clip LEDs to help match a source to amp and optimize output.

Specifications
Input Sensitivity
150 mV - 12 V
Recommended Fuse
(not included)
100 A
Average Current Draw (13.8V Music)
45 A
Efficiency (average)
68% @ 4-Ohm
Dynamic Power
(PVC/PowerCube®)
129 Watts x 4 @ 4-Ohms 0° Res
211 Watts x 4 @ 2-Ohms 0° Res
Shipping Weight
12.8 Lbs. (5.80 Kg.)
CEA-2006 Compliant
CEA-2006 Power Rating
75W x 4 @ 4Ω
≤1.0% THD+N
Suggested Alternator
75 A
Operating Voltage
9 - 16 VDC
Max. Current Draw (13.8V Sinewave)
90 A
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
Crossover Controls
Front/Rear High-Pass (HP): 50Hz-250Hz @ 12dB/octave Butterworth
Front/Rear Low-Pass (HP): 50Hz-250Hz 12dB/octave Butterworth
All-Pass: Yes
Number of Channels
4
Rated Power
(RMS Continuous Power)
75 Watts x 4 @ 4-Ohm
150 Watts x 4 @ 2-Ohm
300 Watts x 2 @ 4-Ohm Bridged
Total Power
(Sum of Rated Power)
600 Watts
Bridgeable
Yes
Tone Controls
Front Punch EQ2 Bass: 0dB to +18dB @ 45Hz and/or
Front Punch EQ2 Treble: 0dB to +12.5dB @ 12kHz
Rear Punch EQ2 Bass: 0dB to +18dB @ 45Hz and/or
Rear Punch EQ2 Treble: 0dB to +12.5dB @ 12kHz
Function depends upon LP/AP/HP switch position
Signal Input
Hi/Low level: 2 RCA pair
Signal Output
Low level: 1 RCA pair
Power Input Connector
Captive C-Clamp
Power Wire Gauge
4 AWG
Speaker Output Connector
Captive C-Clamp
Speaker Wire Gauge
8 AWG to 18 AWG
Heat Sink Type
Cast aluminum
Cooling
Convection
Remote Controls
Optional Punch Level Control (PLC2) Ready
Visual Indicators
Power/Protect/Thermal LED
Input Clip LED3
Output Clip LED1,2,3

LED Color Legend:
1BLUE: <0.5% THD
2VIOLET: 1% THD
3RED: 10%+ THD
Circuit Topology Class
Class A/B
Frequency Response
20Hz to 20kHz +/- 1.0dB
Dimensions (H x W x D)
2.38 x 7.76 x 13.28 (in)
6.05 x 19.71 x 33.73 (cm)
Dimensional Diagram
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.
