T1S1-12

Power 12" T1 Slim Single 1-Ohm Subwoofer

The Power T1S1-12 is a slimline 12" subwoofer designed for spaces where traditional sized woofers will not fit. Features a single 1-ohm voice coil for simplified wiring configurations.

  • Carbon fiber/PMI/glass fiber cone with aluminum dustcap
  • Injection molded foam surround with VAST™
  • Dual Nomex progressive spiders with integrated lead wires
  • Aluminum diecast frame with integrated heat sink fins
  • Custom insulated push spring 10 AWG terminals
  • Dual wound 2.5" voice coil with interior/exterior windings
  • Encapsulating voice coil to former coupling technology (patent pending)
  • Detachable die cast aluminum trim ring
  • Vented pole piece
  • High temp high energy neodymium motor structure
  • Proprietary split yoke pass thru motor technology (patent pending)
  • Integrated copper cap heat sinking shorting ring (IDHS)
  • Optional grille insert available
  • Optimized for sealed enclosures
  • 1 Year Standard Warranty warranty info
USD 549.99


Find Dealer

T1S1-12

Need bass but don’t have a lot of space?  How about more power handling than your average shallow subwoofer?  Well, the T1 "Slimline" subwoofers are not your average shallow, in fact, they have been painstakingly designed to near exact performance characteristics of traditional sized Power T1 subwoofers you’re already familiar with.

We’re calling these SLIM subwoofers because they don’t require a lot of depth and offer bass response similar to a traditional sized model.  How can this be true?  Well, let’s just say the Wizards-of-Fos engineered an ingenious slotted voice coil assembly that exhibits long excursion travel.  Don’t worry, you don’t need to understand it, you just have to listen to how awesome they sound!
Updated: 5/9/2017
CEA-2031

CEA-2031

Power handling on Rockford Fosgate speakers conform to CEA-2031 industry standards.
Learn more
Klippel Verified

Klippel Verified

Klippel is a speaker certification program allowing us to deliver the best possible subwoofers.
Learn more
Encapsulated Voice Coil Coupling

Encapsulated Voice Coil Coupling

Our EVCC (Encapsulated Voice Coil Coupling) technology connects to the woofers voice coil from both...
Learn more
Split Yoke Motor Technology

Split Yoke Motor Technology

The unique motor structure design allows full excursion capabilities of the woofers voice coil...
Learn more
Inductive Damping Heat Sink

Inductive Damping Heat Sink

Secures directly to the top of magnet structure to improve system efficiency by reducing both...
Learn more
VAST Surround - Subs

VAST Surround - Subs

The Vertical Attach Surround Technique significantly increases a subwoofer's effective radiating...
Learn more
FlexFit Basket - Subwoofer

FlexFit Basket - Subwoofer

The slot mounted frame pattern allows fine-tuning of the subwoofer's mounting position.
Learn more
Anodized Aluminum Voice Coil Former

Anodized Aluminum Voice Coil Former

Rockford Fosgate subwoofers use anodized aluminum voice coil formers that provide superior heat...
Learn more
Stitched Tinsel Leads

Stitched Tinsel Leads

Improved reliability and performance by reducing fatigue and possible shorting.
Learn more
CEA-2031 Compliant: CEA-2031 Guidelines
Size: 12"
Subwoofer Type: Shallow
Power Handling (Watts RMS): 600 Watts RMS
1200 Watts Max
Nominal Impedance: 1-Ohm
Voice Coil Type: Single Voice Coil
Voice Coil Diameter: 2.98" (75 mm)
Magnet Weight (oz): 14.42 oz. (0.41 Kg)
Speaker Connector: 10 AWG slot loaded
Fs (Hz): 37
Re (Ohms): 1.7
Le (mH): 0.31
Qms: 11.22
Qes: 1.17
Qts: 1.06
Vas (Liters): 32.4
Sd (cm2): 560
SPL (dB @ 1w/1m): 84
Xmax (mm): 15
Sealed Box Volume (Vb): 1.1 cu. ft. (31.1 Liters)
Vented Box Volume (Vb): 2.0 cu. ft. (56.6 Liters)
Woofer Displacement: 0.042 cu. ft. (1.2 Liters)
Cutout Diameter: 11.22 in. (285 mm)
Mounting Depth: 3.01 in. (76.5 mm)
Shipping Weight: 16.15 Lbs. (7.3 Kg.)

Customer Discussion Forums

NOTE: Views expressed by fanatics in our customer forum may not represent the views of Rockford Fosgate.

No recent Discussion Forum topics posted
Show all Customer Discussion Forums

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.

View Process
RFTECH Support
Find Answers
Find Answers

Search for answers regarding the t1s1-12.

Ask A Question
Ask A Question

Submit a question to our RFTECH staff about the t1s1-12.

My Stuff
My Stuff

View status of current inquiry or review question history.

T1SG-12
Grille Insert

Power T1 12" Slim Mesh Grille Insert
MSRP $24.99

read more...
RFWP12-15
RFWP12-15

12 AWG Speaker Wire Packaged 15 Foot Black/Silver
MSRP $24.99

read more...
RFDS-TRUNK
RFDS-TRUNK

Sound Deadening Trunk Kit
MSRP $170.99

read more...
Rockford FosgateWoofer WiringWizard



Available Wiring Diagrams


Please consult your amplifier owner's manual for lowest recommended impedance.

Wiring Diagram #1


Wiring Diagram #2


Wiring Diagram #3


Wiring Diagram #4


Wiring Diagram #5


Wiring Diagram #6


Wiring Diagram #7


Speaker Polarity
Your woofer may use one of the following to identify (+/-) terminals.
Positive +
Red Post
Purple (4Ω)
Red (8Ω)
Negative -
Black Post
No Dot
No Dot
EBP

Please rotate mobile device to landscape to view graph.

Amp Power Range

Please rotate mobile device to landscape to view graph.

Sealed Recommended Design
This is the optimum recommended sealed woofer enclosure and replicates the optimum enclosure listed in the owner's manual. You may notice slight differences between online information and the owner's manual due to continual improvement on usage of our products.
  • All sides use 3/4" (18mm) thick MDF.
  • All box dimensions are external.
  • Dimensions above include Vb + woofer displacement.
  Standard Metric
Vb (Gross) 1.10 cu. ft. 31.15 Liters
F3 39.90 Hz
Qtc 1.18
Height 13.00 in. 33.02 cm
Width 22.00 in. 55.88 cm
Depth 9.50 in. 24.13 cm
Spk. Cutout 0.000 in. 0.000 cm
Spk. Depth 3.01 in. 7.65 cm
Vd 0.000 cu. ft. 0.000 Liters

EXPORT

Modify This Box Wire This Woofer
Vented Recommended Design
This is the optimum recommended vented woofer enclosure and replicates the optimum enclosure listed in the owner's manual. You may notice slight differences between online information and the owner's manual due to continual improvement on usage of our products.
  • All sides use 3/4" (18mm) thick MDF.
  • All box dimensions are external.
  • Dimensions above include Vb + woofer/port displacement.
  • Port diagram for reference only and may require alternate placement.
  • An infrasonic filter is required for reliable performance in vented designs.
  Standard Metric
Vb (Gross) 2.00 cu. ft. 56.63 Liters
F3 28.00 Hz
Fb 35.00 Hz
Height 14.50 in. 36.83 cm
Width 22.50 in. 57.15 cm
Depth 14.25 in. 36.20 cm
Np 1 port
Dp 4.00 in. diameter 10.16 cm diameter
Lp 13.00 in. long 33.02 cm long
Spk. Cutout 0.000 in. 0.000 cm
Spk. Depth 3.01 in. 7.65 cm
Vd 0.000 cu. ft. 0.000 Liters
Vp 0.095 cu. ft. 2.677 Liters

EXPORT

Modify This Box Wire This Woofer
Infinite Baffle Design
Not Recommended for Infinite Baffle
  • Baffle board uses 3/4" (18mm) thick MDF.
  • Baffle board & cavity air leaks can cause significant performance loss.
  • For optimum results, ensure cavity & baffle board are air tight.
  • An infrasonic filter is required for reliable performance in IB designs.

Do Not Use Infinite Baffle

This woofer is not recommended for Infinite Baffle; it is optimized for the design(s) above. If you require this type of design, here are some recommendations:

  • Select another Woofer Family (M1, M2, etc).
  • Select another Woofer Series (Prime, Punch, etc.).
  • Select another Woofer Size (10", 12", etc).
