Prime Marine 1,200 Watt Class-D Mono Amplifier M1200-1D

The M1200-1D is a 1200 Watt mono high efficiency Class-D marine amp featuring a Marine grade PC Board, on-board Punch EQ, infrasonic filter, variable crossover and tri-state protection circuits.

Read More
0 Reviews
Discontinued
Overview

The Prime M1200-1D amplifier is a 1200 Watt mono high efficiency Class-D amplifier specifically designed for Marine and Powersport applications. The amplifier features a Marine grade PC Board, and the Class-D circuit topology is so efficient, it consumes much less current from your charging system over traditional Class-A/B amplifiers.

  • Marine grade two part epoxy coating on circuit boards
  • 12 dB/Oct Butterworth crossovers
  • Infrasonic filter
  • Remote PLC (Punch Level Control)
  • On-board Punch EQ with +18dB boost @ 45Hz
  • RCA pass-thru outputs
  • On-board Punch EQ with +18dB boost @ 45Hz
  • Real time output and power supply thermal sensing
  • Remote PLC (Punch Level Control)
  • Cast aluminum heat sink
  • Top mounted controls
  • 4 Gauge power/ground connectors
  • MOSFET power supply
  • Short circuit protection
  • Muted turn on
  • 2-Year Warranty
Technologies
Element Ready™ - Amps

These amplifiers are protected against Dust, UV, Corrosion, and feature Stainless hardware.

Learn more
CEA-2006

Power ratings on Rockford Fosgate amplifiers conform to CEA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

Learn more
Class-D

High efficiency amplifier design that reduces current consumption from the charging system.

Learn more
Specifications
CEA-2006 Compliant
CEA-2006 Guidelines CEA-2006 Power Rating
400W x 1 @ 4Ω
≤1.0% THD+N
Cta-2006 Compliant
Number of Channels
1
Total Power
(Sum of Rated Power)
1200 Watts RMS
Rated Power
(RMS Continuous Power)
400 Watts x 1 @ 4-Ohm
800 Watts x 1 @ 2-Ohm
1200 Watts x 1 @ 1-Ohm
Dynamic Power
(PVC/PowerCube®)
485 Watts x 1 @ 4-Ohm
854 Watts x 1 @ 2-Ohm
1256 Watts x 2 @ 1-Ohm
Bridgeable
No
Frequency Response
20Hz to 250Hz +/-1dB
Input Sensitivity
Circuit Topology Class
Class D
Efficiency (average)
85% @ 4-Ohm
85% @ 2-Ohm
80% @ 1-Ohm
Total Harmonic Distortion (Thd+Noise)
Signal Input
Low Level: 1 RCA Pair
Signal Output
Low Level: 1 RCA Pair
Tone Controls
0dB to +18dB @ 45Hz
Crossover Controls
Variable 50Hz - 250Hz @ 12dB/octave
Remote Controls
Punch Level Control
(when connected, is linked to "gain control" to provide remote output level)
Visual Indicators
Power
Protect
Power Wire Gauge
4 AWG
Power Input Connector
Block
Speaker Wire Gauge
12 AWG
Speaker Output Connector
Block
Cooling
Convection
Heatsink
Operating Voltage
Recommended Fuse
(Not Included)
Average Current Draw (13.8V Music)
Max. Current Draw (13.8V Sinewave)
Suggested Alternator
Dimensional Diagram
Dimensions (H x W x D)
1.97" x 6.77" x 11.06"
(5cm x 17.20cm x 28.10cm)
Shipping Weight
7.825 Lbs.
(7.82 Kg.)
Compatibility
Support

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.

The below diagrams optimize this amp for its lowest recommended MONO load.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6



Wiring Diagram #7



Wiring Diagram #8



Wiring Diagram #9



Wiring Diagram #10

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
