Prime 250 Watt 4-Channel Amplifier R250X4

The Prime R250X4 is a 250 watt 4-channel amplifier capable of running 2-Ohms stereo on all channels and 4-Ohms bridged/mono on the rear channels. Includes on-board Punch Bass and front/rear crossover controls.

• This model replaced by the R2-300X4

Read More
0 Reviews
Discontinued
Overview

The Prime R250X4 is a 4-Channel amplifier perfect for any Car Audio Fanatic getting into mobile audio wanting a single amplifier to run a complete audio system. This amplifier features selectable Punch Bass to tune low frequencies, variable crossovers to either protect your high frequency speakers or feeding only bass to your subwoofers.

FEATURES AT A GLANCE

  • 12dB/octave Butterworth crossover
  • 2/4 channel input switch
  • Separate Front and Rear Gain Control
  • High Level Input (4-pin)
  • 0/6/12 dB On Board Punch EQ Control
  • Real time output and power supply thermal sensing
  • MOSFET power supply
  • 4 Gauge power/ground connectors
  • Cast aluminum heatsink
  • Over current protection
  • Short circuit protection
  • Muted turn on
  • 1 Year Warranty
Technologies
CTA-2006 Compliant

Power ratings on Rockford Fosgate amplifiers conform to CTA-2006 industry standards. These guidelines mean your amplifier's ...

Learn more
CE Compliant

This product fulfills all essential safety and environmental requirements as defined in the European Directives (768/2008 ...

Learn more
Class-A/B

An amplifier topology with the best of both worlds; a Class-A preamp and Class-B output stage.

Learn more
Specifications
Cta-2006 Compliant
Number of Channels
4
Total Power
(Sum of Rated Power)
250 Watts RMS
Rated Power
(RMS Continuous Power)
40 Watts x 4 @ 4-Ohms
60 Watts x 4 @ 2-Ohms
125 Watts x 2 @ 4-Ohms Bridged
Dynamic Power
(PVC/PowerCube®)
54 Watts x 4 @ 4-Ohms 0° Res
82 Watts x 4 @ 2-Ohms 0° Res
Bridgeable
Yes
Frequency Response
20Hz to 20kHz +/-1dB
Input Sensitivity
150 mV to 4 V
Circuit Topology Class
Class A/B
Efficiency (average)
64% @ 4-Ohm
Total Harmonic Distortion (THD+Noise)
4-Ohm: <1.0%
2-Ohm: <1.0%
Signal Input
Low Level: 2 RCA Pair
High Level: 2 x 4-pin MOLEX
Signal Output
-
Tone Controls
Punch Bass: 0dB/+6dB/+12dB @ 45Hz
Crossover Controls
Front Channels
High-Pass/Low-Pass (HP/LP): 50Hz-250Hz @ 12dB/octave Butterworth

Rear Channels
High-Pass/Low-Pass (HP/LP): 50Hz-250Hz @ 12dB/octave Butterworth
Remote Controls
-
Visual Indicators
Power/Protect LED
Power Wire Gauge
4 AWG
Power Input Connector
Barrier Strip
Speaker Wire Gauge
8 AWG
Speaker Output Connector
Barrier Strip
Cooling
Convection
Heatsink
Operating Voltage
9 - 16 VDC
Recommended Fuse
(not included)
50 A
Average Current Draw (13.8V Music)
20 A
Max. Current Draw (13.8V Sinewave)
40 A
Suggested Alternator
75 A
Included In The Box
Dimensions (H x W x D)
1.98 x 6.77 x 11.22 (in)
5 x 17.2 x 28.5 (cm)
Shipping Weight
7 Lbs. (3.17 Kg.)
Compatibility
Support

Knowledge Base Articles

  • No Knowledge Base articles

Show all Knowledge Base topics

Ask Our Experts

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Accessories Wiring Wizard

Available Wiring Diagrams

Please consult your amplifier owner's manual for lowest recommended impedance.

The below diagrams optimize the REAR CHANNELS of this amp for its lowest recommended BRIDGED/MONO load.



Wiring Diagram #1



Wiring Diagram #2



Wiring Diagram #3



Wiring Diagram #4



Wiring Diagram #5



Wiring Diagram #6



Wiring Diagram #7



Wiring Diagram #8



Wiring Diagram #9



Wiring Diagram #10

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot

Speaker Polarity

Your woofer may use one of the following to identify (+/-) terminals.

Positive +

Red Post

Purple (4Ω)

Red (8Ω)

Negative -

Black Post

No Dot

No Dot
