Hide Away AM/FM/SAT/MP3 Digital Media Receiver RFX6000-SX

Placeholder, no image available
Placeholder, no image available

Hide Away AM/FM/SAT/MP3 Digital Media Receiver RFX6000-SX

The RFX6000-SX is a “Hide-Away” black box AM/FM stereo perfect for when you need tunes but only have room for a small control unit. It features front/rear/sub outputs and an AUX/USB inputs for connection of your favorite music. SiriusXM ready. Requires RFXMR5BB.

Read More
0 Reviews
Discontinued
Overview Technologies Specifications Support Accessories
Overview

The RFX6000-SX is a “Hide-Away” black box AM/FM stereo perfect for when you need tunes but only have room for a small control unit. It features front/rear/sub outputs and an AUX/USB inputs for connection of your favorite music. SiriusXM ready.  Supports up to 3 remotes.

RFXMR5BB required to operate.

FEATURES AT A GLANCE

  • Bass/Treble, Balance/Fade, and EQ control (w/ RFXMR5BB)
  • 24 station presets with USA/Europe switching (w/ RFXMR5BB)
  • AM/FM stereo radio
  • iPod/iPhone input (up to 4S, IPODEC sold separately)
  • Wireless Bluetooth ready (w/ RFXBT module)
  • Digital audio player
  • Front and rear RCA output
  • 4 channel speaker outputs
  • SiriusXM-Ready™ (SXV200 module)
  • iPod/iPhone on-screen display (w/ RFXMR5BB controller)
  • Subwoofer output
  • Dual volume zone control
  • USB/SD Input
  • Dual 12 VDC trigger output
  • Aux Audio Input
  • Composite video input/output
  • Oversized 1.75 DIN faceplate
  • Epoxy coated circuit board for water resistance
  • 1 Year Warranty
Technologies
MP3 Playback

This source unit supports MP3 file format playback.

Learn more
WMA Playback

This source unit supports WMA file format playback.

Learn more
USB Playback

This source unit supports playback from a USB device.

Learn more
SiriusXM-Ready®

This radio is ready to accept SiriusXM® programming.

Learn more
SD/SDHC Playback

This source unit supports playback of media from an SD or SDHC media card.

Learn more
AVI Video

AVI is an audio/video data file allowing synchronous audio-with-video playback.

Learn more
Made for iPod/iPhone

This device supports the Apple "Made for iPod/iPhone" protocol.

Learn more
MPEG-4 Video

MPEG-4 is an audio and video compression method standardized by MPEG group.

Learn more
DivX Video

DivX compress video segments into small sizes with high visual quality.

Learn more
XviD Video

XviD is an open source format used to encode and decode digital video.

Learn more
Wireless Bluetooth® Ready

Supports audio streaming via Bluetooth®.

Learn more
Specifications
FM TUNER
Channel Step
FM TUNER
Sensitivity
8 dB
FM TUNER
Stereo Separation
FM TUNER
Signal-to-Noise Ratio
AM TUNER
Frequency Range
530 - 1710 kHz
AM TUNER
Usable Sensitivity
32 dBµV
RCA Output Impedance
<1000 Ohms
Operating Voltage
9 - 16 VDC
Speaker Impedance
4-Ohms
Power Output
50 Watts x 4
Fuse Rating
AM TUNER
Channel Step
AM TUNER
Signal-to-Noise Ratio
Dimensions (HxWxD)
Chassis
H2.25" x W8" x D6.5" (57mm x 203mm x 165mm)
MEDIA PLAYER
Audio Format Compatibility
MP3
WMA
MEDIA PLAYER
Video Format Compatibility
MPEG-4
DivX 3.11
DivX 4.12
DivX 5.x
DivX Pro
XviD
AVI
Rmp4
Shipping Weight-
3.6 Lbs. (1.6 Kg.)
Compatible Remotes
Remote Controllers:
RFXMR5BB (required)
RFXMR6
RFXMR6.5
RFXMR7
RFXMR8
FM TUNER
Frequency Range
87.5 - 107.9 MHz
RCA Output Voltage
Front: 3 Volts (max)
Rear: 3 Volts (max)
Sub: 3 Volts (max)
MEDIA PLAYER
Supported Devices
SD/SDHC memory card
USB memory stick
Compatibility
Support

Knowledge Base Articles

  • No Knowledge Base articles

Show all Knowledge Base topics

Ask Our Experts

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Return Authorization Process



Diagnose First

Prior to requesting an RA, try to diagnose the failure. Many products we receive are sent back with No Trouble Found, usually due to incorrect installation. Use our RFTECH:Knowledge Base for troubleshooting assistance.



Contact Customer Support

Please call us during normal business hours at 1-800-669-9899 (option #1) and be prepared with the following information:

  • First and Last Name with complete Shipping Address
  • Product Name (T0D415)
  • Serial Number (12 or 13 digit number)
  • Failure Diagnosis (no output, no power LED, etc.)
  • Scanned copy of Original Receipt emailed to [email protected] (dealer name, purchase date, and item purchased must be legible)
  • Credit/Debit Card (if paying for out-of-warranty claims)
  • No money orders or checks.


Shipping Instructions

When shipping your product, your package MUST have the following information:

  • RA# Printed Outside of Box (as large as possible)
  • Copy of Original Receipt


Shipping Address

Ship your product (UPS or FedEx preferred) to the following:


Rockford/ AJR International
300 Regency DR
Glendale Heights, IL 60139
RA#:_______________________
