1,000 Watt Can-Am X3 MAX Rear Subwoofer Solution (Gen-3) X317MAX-RSS

Purpose Built exclusively for select Can-Am® X3 MAX models, this dual rear subwoofer kit provides next level bass performance, an Element Ready™ design, and simple installation. The kit is designed as an upgrade for select aftermarket Rockford Fosgate Can-Am Stage-3/4/5/6 systems. It features two Element Ready™ 10" loaded subwoofer enclosures and 1,000 watt, next-generation IPX6 Element Ready™ amplifier.  Includes all necessary wiring harnesses and hardware. Fits 4-seat models only.  Does not fit 2-seat models.  See COMPATIBILITY chart to verify system requirements and fitment before purchasing.

Click to watch video X317MAX-RSS Install Video

Read More
0 Reviews
NEW
$1869.99
Checking product inventory...
+
+

Notify Me When Back In Stock:

Thanks! You're on the list!

Overview

Plug-n-play system easily integrates into existing Rockford Fosgate aftermarket audio systems. Audio system is 100% Element Ready™ solution and provides ability to take your off-road vehicle into any environment. The subwoofer enclosures mount underneath the rear driver and passenger seats, and the amplifier mounts inside the rear center tunnel.  Amplifier also employs the Rockford Fosgate PRESET switch for easy set-up, allowing maximum performance without any tuning. System features a plug-and-play design and does not require any cutting or drilling of vehicle.  A step-by-step install video is available for DIY installations.

  • Bass upgrade for select Can-Am stage kits
  • Uses factory mounting locations for easy install
  • M2 10” IPX6 Element Ready™ loaded subwoofers in enclosures under rear seats
  • Down firing configuration for improved performance
  • Custom fit left and right sealed subwoofer enclosures
  • Roto-mold design for lightweight and durable seamless construction
  • Enclosure textured to match factory finish
  • M5-1000X1: 1,000-watt mono IPX6 Element Ready™ amplifier
  • Vehicle specific wiring harness and mounting plate for amplifier
  • Amp PRESET engages Rockford Fosgate tune, eliminating need for manual setup
Videos

X317MAX-RSS Installation Tutorial

The installation tutorial covers the aftermarket Rockford Fosgate X317MAX-RSS rear subwoofer solution for select 2017+ Can-Am® MAVERICK X3 MAX models. Verify compatibility before purchase.

Technologies
Maximum Bass Performance

With 1,000 watts of output, the Element Ready™ amplifier and dual subwoofers deliver that next level ...

Learn more
Element Ready - Motorsports

These products are protected against Dust, UV, Temperature, Water, Corrosion & Vibration.

Learn more
Plug and Play

This product is designed for rapid installation.

Learn more
Rockford Factory Fit and Finish

Designed and engineered to match and compliment the factory fit and finish of your vehicle. These ...

Learn more
Specifications
CEA-2031 Compliant
CEA-2031 Guidelines
Woofer Quantity
2
Woofer Size
10"
Woofer Series
M2D2-10IB
Nominal Impedance (ea)
2Ω (4Ω each enclosure wired in parallel to create a 2Ω amp load)
Frequency Response
20 Hz – 750 Hz
Sensitivity
90.3 dB
Power Handling (Watts RMS)
500 Watts RMS
1,000 Watts Peak
Enclosure Type
Infrasonic: 30 Hz @ 12dB/Octave
Enclosure Type
Sealed
Enclosure Material
Roto-molded HDPE
Speaker Connector
2-pin Deutsch™/Amphenol™
Dimensions
Box (H x W x D)
Wedge (H x W x D1 x D2)
19.97” x 18.82” x 8.06” (each enclosure)
(608 cm x 573 cm x 245 cm)
In The Box
(2) Pre-loaded subwoofer enclosures
(4) Enclosure mounting brackets
(4) Spacer washers
(12) Bracket and enclosure mounting screws
(4) Amp mounting screws
(1) Amp plate mounting push clip
(1) Amp Bracket
(6) Zip ties
(1) Enclosure speaker harness
(1) Amp power and input signal harness
Shipping Weight
16.5 Lbs. (7.48 Kg)
Compatibility

YES

Can-Am X3 4-Seat 4-Seat Model

NO

Can-Am X3 2-Seat 2-Seat Model

YES

Bucket Seats Bucket Seats

NO

Bench Seats Bench Seats



Required Audio System

YEAR GENERATION MODEL DESCRIPTION
2021⁠—current Gen-3 X317-STG3 PMX-2, 800 Watt, Front Color Optix™ Speaker and Subwoofer Kit for Select X3 Models
2021⁠—current Gen-3 X317-STG4 PMX-2, 800 Watt, Front Color Optix™ Speaker, Subwoofer & Rear Speaker Kit for Select X3 Models
2021⁠—current Gen-3 X317-STG5 PMX-3, 1500 Watt, Front Color Optix™ Speaker, Dual Subwoofer and Rear Speaker Kit for Select X3 Models
2021⁠—current Gen-3 X317-STG6 PMX-3, 1500 Watt, Front Color Optix™ Speaker, Dual Subwoofer and Rear Horn Speaker Kit for Select X3 Models
2019⁠—2020 Gen-2 X317-STAGE3 400 watt stereo, front speaker, and subwoofer kit for 2017+ Maverick X3 models
2019⁠—2020 Gen-2 X317-STAGE4 400 watt stereo, front speaker, subwoofer, & rear speaker kit for 2017+ Maverick X3 models
2019⁠—2020 Gen-2 X317-STAGE5 1000 watt stereo, front speaker, subwoofer, & rear speaker kit for 2017+ Maverick X3
2017⁠—2018 Gen-1 X3-STAGE3 400 watt stereo, front speaker, and subwoofer kit for 2017-2018 Maverick X3 models
2017⁠—2018 Gen-1 X3-STAGE4 400 watt stereo, front speaker, subwoofer, & rear speaker kit for 2017-2018 Maverick X3 models
2017⁠—2018 Gen-1 X3-STAGE5 1000 watt stereo, front speaker, subwoofer, & rear speaker kit for 2017-2018 Maverick X3 models



Compatible Can-Am® X3 Models

MODEL Can-Am X3 MAX Can-Am X3 Dash 2017 Can-Am X3 MAX Can-Am X3 Dash 2018 Can-Am X3 MAX Can-Am X3 Dash 2019 Can-Am X3 MAX Can-Am X3 Dash 2020 Can-Am X3 MAX Can-Am X3 Dash 2021 Can-Am X3 MAX Can-Am X3 Dash 2022
Maverick X3 MAX Turbo
Maverick X3 MAX Turbo R
Maverick X3 MAX DS Turbo
Maverick X3 MAX DS Turbo R
Maverick X3 MAX X DS Turbo RR
Maverick X3 MAX RS Turbo R
Maverick X3 MAX X RS Turbo RR
Maverick X3 MAX X MR Turbo RR
Maverick X3 Turbo
Maverick X3 Turbo R
Maverick X3 DS Turbo
Maverick X3 DS Turbo R
Maverick X3 X DS Turbo
Maverick X3 X DS Turbo RR
Maverick X3 RS Turbo R
Maverick X3 X RS Turbo
Maverick X3 X RS Turbo RR
Maverick X3 X MR Turbo
Maverick X3 X MR Turbo RR
Maverick X3 X RC Turbo
Maverick X3 X RC Turbo RR
