Balanced Line Driver RF-BLD

The RF-BLD is a 2-channel line driver that boosts low source unit signals or drives amplifiers located a long distance to the back of a vehicle. The BLD features Single Ended or Balanced Differential mode to eliminate noise.

• This model has no equivalent replacement :-(

Read More
0 Reviews
Discontinued
Overview Technologies Specifications Support
Overview

If your source unit has low output voltage or your amplifiers are located far back in a Van or SUV, the BLD is a perfect for your system. Featuring 'Balanced Differential' or 'Single Ended' mode, its high voltage output combined with a low output impedance will drive large arrays of amplifiers without breaking a sweat. In 'Balanced Differential' mode, it's twisted pair design also helps eliminate radiated noise through electrical cancellation.

FEATURES AT A GLANCE

  • High voltage line driver
  • Selectable Balanced Differential or Single Ended inputs / outputs
  • Speaker Level to RCA Line Level Converter
  • Low output impedance
  • Output level indicators
  • 2 channel inputs/outputs
  • Low distortion, low noise operation
  • 1 Year Warranty
Technologies
Low Output Impedance

Ability of a processor to drive a noise free signal to an amplifier or large array ...

Learn more
Balanced/Unbalanced Signal Output

The Balanced and Unbalanced mode allows the output signal to properly match the input of the ...

Learn more
Differential Inputs

Differential inputs eliminate noise picked up by signal cables resulting in clean signal transfer.

Learn more
Specifications
Processor Type
Line Driver
Signal Input
High-Level: 2-channel (left/right)
Low-Level: (2) RCA (left/right)
Signal Output
Low-Level: (2) RCA (left/right)
Input Voltage
650mV to 10.5V RMS
THD+N
0.01%
Dimensions (H x W x D)
H 1.32" x W 5.90" x D 4.09"
3.35cm x 15.0cm x 10.38cm
Shipping Weight
1.1 Lbs.
(0.49 Kg.)
Operating Voltage
9-16 VDC
Frequency Response
20Hz - 50kHz ±1dB
Output Voltage
11 Vrms Unbalanced
22 Vrms Balanced
Signal-to-Noise
≥ 90dB @ 2V ('A' Weighted)
≥ 110dB @ 10V ('A' Weighted)
Mounting
Behind Dash (install as close to source unit as possible)
Output Impedance
55 Ohms
Gain
+0.8dB to +24dB
Input Impedance
20k Ohms
Compatibility
Support

Knowledge Base Articles

  • No Knowledge Base articles

Show all Knowledge Base topics

Ask Our Experts

Return Authorization

Contact the Authorized Rockford Fosgate Dealer you purchased this product from. If you need further assistance, call 1-800-669-9899 for Rockford Customer Service. You must obtain an RA# (Return Authorization number) to return any product to Rockford Fosgate. You are responsible for shipment of product to Rockford.


Return Authorization Process



Diagnose First

Prior to requesting an RA, try to diagnose the failure. Many products we receive are sent back with No Trouble Found, usually due to incorrect installation. Use our RFTECH:Knowledge Base for troubleshooting assistance.



Contact Customer Support

Please call us during normal business hours at 1-800-669-9899 (option #1) and be prepared with the following information:

  • First and Last Name with complete Shipping Address
  • Product Name (T0D415)
  • Serial Number (12 or 13 digit number)
  • Failure Diagnosis (no output, no power LED, etc.)
  • Scanned copy of Original Receipt emailed to [email protected] (dealer name, purchase date, and item purchased must be legible)
  • Credit/Debit Card (if paying for out-of-warranty claims)
  • No money orders or checks.


Shipping Instructions

When shipping your product, your package MUST have the following information:

  • RA# Printed Outside of Box (as large as possible)
  • Copy of Original Receipt


Shipping Address

Ship your product (UPS or FedEx preferred) to the following:


Rockford/ AJR International
300 Regency DR
Glendale Heights, IL 60139
RA#:_______________________
